ATOM SE / PRO
10cm / 4.5" Hologram Display Files
Video Tutorials
Safety Precautions
The fan blade while in motion or speaker grill on the back
Impacts, Dropping or excessive movement
Water, dust, moisture and extreme temperatures
Do not use in strong daylight, IR light from sun overpowers orientation sensor
When operating around children and pets or when unattended
Using sticky tack or anti slip mat if placed on a high slippery surface
Troubleshooting
Technical Issues
General Issues
I can't connect to the wifi on Samsung
As of right now, Samsung devices are unsupported due to a hardware limitation preventing Samsung devices from establishing a connection.
Please use the windows software or upload files directly to the SD card using the provided reader and pre-processed .BIN files
The app is blank / failed to connect
- Please first ensure that you are connected to the device via wifi.
- Allow 1-2 minutes for the device to find your phone's signal and connect.
- If you are still struggling to connect, please try closing the app & reopening it.
- You can also try disconnecting from the display's wifi and reconnecting
- If this doesn't work, please try unplugging the device, and reconnecting it, allowing the device to restart.
Blue dot in the middle of the display
When the Atom displays a blue dot, it means the device cannot detect an SD card. Start by ejecting the SD card and reinserting it to ensure it is properly seated. If the issue continues, try formatting the SD card to FAT32 on a computer.
Be aware that formatting the card will erase all holograms currently on it, and you will need to upload them again.
If you have a different SD card available, you can also test by inserting that card into the Atom. Load a hologram onto the new card and check if the issue persists.
I can't upload any new videos
If you try uploading new videos but the videos aren't appearing in the app, you may be out of space on the micro SD card.
Please try deleting one of your existing videos and reuploading to check if it was due to limited storage space.
I hear a static crackling sound
You may hear a static crackling sound when your device is turned on. This is from the speakers. If you need the device to be silent, please press the mute button on the provided remote.
Unfortunately, in order to keep the size of the display portable, we have to use a smaller speaker, this usually comes at the cost of audio quality. In order to keep the device as affordable as possible, we opted for these speakers as we felt the audio quality actually enhances the "hologram" feel.
However we are constantly looking for better alternatives to balance cost with quality as best as we can.
I didn't receive an SD card
The micro SD card comes already inserted into the fan, please check the short side of the fan blade, here you will find the SD.
Simply press down on the SD to eject it.
Can I combine videos into a playlist?
Right now we don't have a way of creating playlists inside the app or on our website, however the display accepts any mp4 video.
So you can download the videos you would like to turn into a playlist, then combine them together in a free app like capcut and export it out to upload.
Please keep in mind that the included SD card has limited space. If you want to upload every video in our archive, you will likely need to purchase additional storage.
